A.C.T. 3Zero
A.C.T. - 'ADVANCED COMPOSITE TECHNOLOGY'
A.C.T. - ‘Advanced Composite Technology’ - a reference to the composite technologies upon which the Wilson Benesch brand was founded and subsequently has become synonymous with. The A.C.T. acronym was first used in 1991 for the company’s first loudspeaker, the A.C.T. One. The technology was subsequently used in the ‘A.C.T. Two’, the ‘A.C.T.’, the ‘A.C.T. C60’ and in the previous generation A.C.T. One Evolution. The new A.C.T. 3zero, therefore, follows a long line of speakers, embodying the heritage of the Wilson Benesch brand and the classic A.C.T. design.
DRIVE TECHNOLOGY | Midrange | 170mm(7") Wilson Benesch Tactic 3.0 |
Tweeter | 25mm (1”) Wilson Benesch Fibonacci Hybrid Silk-Carbon Tweeter | |
Low Bass | 170mm(7") Wilson Benesch Tactic 3.0 | |
Isobaric Drive System 1 | 2x 170mm (7”) Wilson Benesch Tactic in Clamshell Formation | |
CROSSOVER TECHNOLOGY | Midrange | Directly Amplifier Coupled |
Tweeter | Second-Order, 5kHz High Pass Filter | |
Low Bass | First-Order | |
Isobaric Drive System 1 | First-Order 500Hz Low Pass Filter | |
ENCLOSURE TECHNOLOGY | Materials | A.C.T. 3Zero - Advanced Biocomposite Monocoque Technology, Poly-Alloy, Hybridised Construction |
Midrange | Reflex Port Tuned with Laminar Flow Guide | |
Tweeter | Labyrinth Sealed Tweeter Backplate | |
Low Bass | Infinite Baffle Sealed Enclosure | |
Isobaric Enclosure | Infinite Baffle Sealed Enclosure | |
MEASUREMENTS | Type | TBC |
Impedance | TBC | |
Sensitivity | TBC | |
Frequency Response | TBC | |
DIMENSIONS & TERMINATIONS | Height | 1132mm (44.57") |
Width | 194mm (7.64") Baffle // 276mm (10.87") Widest Point of Foot | |
Depth | 376mm (14.8") | |
Weight | TBC | |
Termination | Bi-wirable terminal located on the loudspeaker foot at ground level |
